Maximum Recording Rate
:
Frame: 720 x 480 pixels with 30 IPS (NTSC)
720 x 576 pixels with 25 IPS (PAL)
CIF: 352 x 240 pixels with 120 IPS (NTSC)
352 x 288 pixels with 100 IPS (PAL)
Adjustable Recording Speed
:
Frame: 30, 15, 7, 3 IPS / 25, 12, 6, 3 IPS
CIF: 120, 60, 30, 15 IPS / 100, 50, 25, 12 IPS
Image Quality Setting
:
Best, High, Normal, and Basic
Hard Disk Storage
:
IDE type, ATA66, supported HDD1, support HDD capacity over 400GB
HDD Quick Cleaning
:
Quick clean up the "index system" of the recorded files. 250GB under 2 seconds
Recording Mode
:
Manual / Timer / Motion / Alarm
Refresh Rate
:
120 IPS for NTSC / 100 IPS for PAL
Audio I/O
:
2 audio inputs, 1 audio output (Mono)
Motion Detection Area
:
16 x 12 grids per camera for all channels
Motion Detect Sensitivity
:
4 adjustable variables with precise calculation for motion detection
Pre-alarm Recording
:
Yes (8MB)
USB Interface
:
Support USB 1.1/ 2.0 device
Backup Device
:
USB 1.1 / 2.0 backup device, CD Write and network remote backup
Web Transmitting / Compression Format
:
Motion JPEG
Ethernet
:
10/100 Base-T. Support remote control and live view via Ethernet.
Web Interface
:
Support licensed software AP, and IE browser
Remote Alarm Notification
:
E-mail images, and images uploading to FTP site's specific account
Network Connection
:
Support TCP/IP, PPPoE, DHCP and DDNS function
PTZ control
:
Support PELCO-D protocol
Dwell Time (Sequential Channel Switch)
:
Programmable with adjustable dwell time
Alarm I/O
:
4 inputs, 1 output
Video Loss Detection
:
Yes
Camera Title
:
Support up to 6 letters
Video Adjustable
:
Hue / Color / Contrast / Brightness
Date Display Format
:
YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off
Power Consumption
:
< 42 W
Operating Temperature
:
10°C ~ 50°C (50°F ~ 104°F)
Dimensions (mm)
:
375mm (W) x 61mm (H) x 281mm (D)
System Recovery
:
System auto recovery after power reconnected
Optional Peripheral
:
VGA connector
