Video Standard
:
NTSC or PAL (switch able)
Monitor Display
:
Real Time 30FPS (NTSC) Per Camera
Operating System
:
Embedded Linux
Record Scheduling
:
Daily, weekly, adjustable to specific hour per channel
Record Mode
:
Continuous, Motion, Event, Panic
Remote Access
:
TCP/IP, View, Search, Recording and Control (client software or browser)
Playback
:
Up to 16 channel simultaneous playback
Pre/Post Alarm
:
-5 Secs (Pre), 3 Mins (Post), programmable per camera
VGA Output
:
Standard (for monitors with multi-sync function only)(1024 x 768, 60Hz)
Motion Detection
:
16 x 16 Grid, Sensitivity Levels: 10
Video Inputs
:
4 Ch - 4 inputs, 1Vp-p, CVBS, 75 ohms, BNC
Video Outputs
:
4 Ch - 4 looping outputs
Monitor Outputs
:
1 x BNC Composite Video, S-VHS and VGA
Spot Output
:
4 Ch - 1 x 1Vp-p, CVBS, 75 ohms, BNC
Audio Inputs
:
4 x line-in, RCA
Audio Output
:
1 x line-out, RCA
Screen Options
:
4 Ch - 1, 4
Resolution
:
352x240, 704x240, 704x480 (NTSC)
Compression Standard -
:
MPEG-4
Recording Speed (ips)
:
352x240: 120 ips, 704x240: 60 ips, 704x480: 30 ips
Image File Size
:
3-5 Kbyte (352x240), 5-10 Kbyte (704x240), 6-16 Kbyte (704x480)
Hard Disk Capacity
:
3 x HDD, No limit on HDD Size
Back-up Storage
:
USB Default (USB Memory Stick included) and/or backup to CD/DVD
media via optional DVD writer
Alarm
:
4 Ch - 4 x TTL, programmable as NC/NO
Alarm Outputs
:
4 Ch - 1 NC/NO
Back-up File Formats
:
AVI, JPG, BMP
Ethernet Interface
:
10/100 Base-TX, RJ-45 connection
Network Control
:
Live View, Recording, Set-up, Playback, Search, Archiving
PTZ Control
:
via RS-485 Interface
PTZ Operation
:
Pan, Tilt, Zoom, Focus, Iris, Preset and Tour
Daylight Savings
:
Included
Time Sync
:
Automatic via NTP
Software Updates
:
via USB memory stick
Security
:
Multi-Level access control via user password
Remote Alarm Notification
:
via SMTP email
Supply Voltage
:
4 Ch - DC12V/5A (adapter Supplied)
Operating Temperature
:
410 - 1040 Fahrenheit
Dimensions
:
4 ch 14.2”x 2.8” x 15.3” (WxHxD)
Rack Mount Size)
:
4 ch - 1.5U (see accessories for optional rack mount kits
Weight
:
- 4 ch - 8.3 lbs.
