IR Mono Focal Lens 6.0 mm / F1.8 (optional: 8.0 / 12 mm)
Synchronous System
:
Internal, Negative sync.
Video Output
:
1 Vp-p / 75 Ohms.
Power consumption
:
0.9 Watt Max.CCD Camera only.
Infrared Luminary
:
84 pieces IR LED, Life: 6000 Hrs.
Wavelength
:
850 nm.
Beam Spread Angle
:
20°/50°
Illuminate Distance
:
30 M
Illuminator Active Limit
:
Under 10 Lux. (linear control.)
Power consumption
:
16 Watt Max. IR-LED ON only.
Power Supply
:
AC100-240V±10% 47-63Hz / 30W typical.
AC24±10% 60Hz / 18W typical.
12V DC±10 % / 1.4 A typical.
( total Power supply require for CCD Camera & IR-LED ON )
